Green Way Regenerative Electric Hot Water uses midnight electric power that is much cheaper than general electricity. It converts electricity into heat, keeps it in the regenerative system, and uses it during daytime. The latest heating system, it is economical enough to save electric rates by a quarter. |
| |
|
| |
|
 |
|
1. It is designed with perfect pressure tank structure. Made of stainless steel, it has good durability and its lifetime is semi-permanent.
2. It is automatically operated by a thermostat. It is designed to have perfect lagging structure so it is excellent at keeping warm.
3. It is available for the places where hot water is frequently used (shower, bath, laundry, and cleaning). It is also used in general houses, dormitories, factories, ranches, fitness centers, hospitals, beauty salons, barber＊s shops, etc.
|
| ≡ Convenient |
| Power is turned on or off by auto timer so it is convenient to use. |
| ≡ Economical |
| It is possible to use hot water for 24 hours a day at the price lowered by a quarter compared with that for general electricity. |
| ≡ Safe |
| Using electricity, it is safe with no danger of explosion or gas poisoning. |
| |
|
 |
|
 |
| Classification |
Standard |
| Consumption
Power
|
1.2KW |
1.5KW |
2.0KW |
2.5KW |
3.0KW |
3.8KW |
4.5KW |
5.0KW |
Standard
Diameter
(白)x height (mm)
|
570白
x1000 |
570白
x1176 |
570白
x1460 |
570白
x1743 |
700白
x1390 |
700白
x1670 |
700白
x1946 |
700白
x2095 |
| Working voltage |
1白 220V |
| Capacity(L) |
120 |
150 |
200 |
250 |
300 |
380 |
450 |
500 |
| Heating type |
Direct heating |
|
|
| |
|
 |
|
The inner material is electric-galvanized steel, which is 0.8T. |
| Inner Materials |
It protects the inner insulation and the inner tank. The inner tank is automatically welded with STS 1.5T for prevention of corrosion and protection of the tank. |
| Electric Heater |
The electric heater is replaceable at the time of disconnection. Its material is Incoloy. A special sealing material is used for the terminal part. It is protected from humidity. |
| Insulation |
An incombustible material (glass wool) is used for insulation. |
| Thermostat |
A bimetal thermostat controls the temperature of the tank within 80◥C▽5◥C. |
| Anti-overheating Device |
A bimetal thermostat controlled at 93◥C▽2◥C is installed to protect the internal tank. |
| Mounting Structure |
The inside of this Hot Water should be able to hold 3Kgf/妓 for 2 minutes, causing no problem (based on KSC9803) |
| Internal Wire |
An incombustible electric wire (3.0妤) is used. |
| Setting Pressure |
2.0Kgf/妓: It should be able to offset the fatigue of the internal tank caused by change in water volume resulting from increase in water temperature (10◥C~80◥C). |
| Automatic Device |
函 Circuit breaker: 1P 30A
刻 Thermostat: To control the set temperature
券 Anti-overheating device: To prevent hot water from being heated at higher than the set temperature |
|
|
| |
|
|
|
|
