Green Way Regenerative Electric Hot Floor Ondol (MI Hit Cable) can be used through only one time installation as long as the lifetime of a building. A smoke electric wire is most important in deciding the lifetime of this Ondol. It is in one system with no connection except for the lead wire that is connected with the controller. Basically, it has no factor for malfunction.
|
| |
|
| |
 |
| ¡Ý Highly durable |
| It is made from insulating materials of natural ores, inorganic materials of high quality, so its lifetime is semi-permanent. |
| ¡Ý Very convenient |
Full automatic, it always keeps the same temperature and heats 24 hours a day efficiently so pleasant and convenient heating is possible all the time. |
| ¡Ý Economical |
| It directly heats natural ores from the bottom so it is efficient. It doesn¡¯t have heat loss resulting from preheating and exhaust gas so it saves energy. Especially it uses cheap midnight electric power so compared with city gas, gasoline, and kerosene, it is economical. |
| ¡Ý Safe |
| It has no danger of explosion or fire and no environmental pollution compared with the existing gas and oil boilers. It is clean and safe. |
| ¡Ý Uses |
It is suitable for apartments, villas, pastoral houses, dormitories, hospitals, libraries, offices, laboratories, schools, and other types of houses. |
|
| |
 |
 |
| Classification |
Room Size |
(M)/Length |
Resistance (¥Ø)
¡¾5% |
Consumption Power (W)
¡¾5% |
Exterior(mm)
¡¾5% |
Remarks |
| GA |
1.5 |
20 |
40 |
1200 |
5.6 |
M.I HEATING CABLE (copper jacketed) |
| GB |
1.8 |
25 |
33 |
1500 |
5.8 |
| GC |
2.1 |
28 |
28 |
1800 |
5.8 |
| GD |
2.5 |
34 |
24 |
2000 |
6.1 |
| GE |
3.0 |
40 |
20 |
2400 |
6.1 |
| GF |
3.5 |
48 |
17 |
2800 |
6.1 |
| GG |
4.1 |
56 |
14.5 |
3300 |
6.3 |
| GH |
4.6 |
65 |
13 |
3700 |
6.6 |
|
|
| |
|
| |
|
|
|
